Node exporter setup: Linux server metrics in Prometheus (2026 guide)

node_exporter is a single static binary that reads /proc and /sys and serves every Linux host metric that matters on port 9100. Setup is ten minutes: binary, system user, systemd unit, firewall rule, one stanza in Prometheus. This guide does all five properly - including the firewall step that most tutorials skip and the shortlist of metrics that deserve alerts, because the default /metrics page emits over a thousand series and maybe ten of them will ever wake you up. It assumes a running Prometheus server (install guide here).

1. Install the binary

From prometheus.io/download - substitute the current version for 1.12.1:

cd /tmp
curl -LO https://github.com/prometheus/node_exporter/releases/download/v1.12.1/node_exporter-1.12.1.linux-amd64.tar.gz
tar xvf node_exporter-1.12.1.linux-amd64.tar.gz
sudo cp node_exporter-1.12.1.linux-amd64/node_exporter /usr/local/bin/
sudo useradd --system --no-create-home --shell /usr/sbin/nologin node_exporter

One deliberate non-step: no Docker. The project itself recommends against containerising node_exporter, because its whole job is reading the host’s /proc and /sys, and a container’s view of those is not the host’s. The static binary under systemd is the supported path.

2. The systemd unit

# /etc/systemd/system/node_exporter.service
[Unit]
Description=Prometheus Node Exporter
Wants=network-online.target
After=network-online.target

[Service]
User=node_exporter
Group=node_exporter
Type=simple
Restart=on-failure
ExecStart=/usr/local/bin/node_exporter \
  --collector.systemd

[Install]
WantedBy=multi-user.target

sudo systemctl daemon-reload
sudo systemctl enable --now node_exporter
curl -s localhost:9100/metrics | head -5

The defaults enable the collectors you want (cpu, meminfo, filesystem, diskstats, netdev, loadavg, and more). --collector.systemd is the one non-default worth adding on servers - it exposes unit states, so you can alert on any service entering failed instead of writing a check per service.

3. Firewall the port - this step is not optional

/metrics is unauthenticated and reveals more than people expect: kernel version, mounted filesystems and their sizes, network interfaces, systemd unit names. Nobody outside your monitoring path should be able to read it.

# Allow only the Prometheus server (adjust the IP), nothing else
sudo ufw allow from 10.0.1.5 to any port 9100 proto tcp
sudo ufw deny 9100/tcp

If exporter traffic crosses untrusted networks, node_exporter also supports TLS and basic auth natively via --web.config.file - worth it between data centres, overkill inside one private subnet.

4. Wire it into Prometheus

On the Prometheus server, add a job to /etc/prometheus/prometheus.yml:

scrape_configs:
  - job_name: "node"
    static_configs:
      - targets: ["10.0.1.10:9100", "10.0.1.11:9100"]
        labels:
          env: "prod"

promtool check config /etc/prometheus/prometheus.yml && sudo systemctl reload prometheus

Status -> Targets in the Prometheus UI should show the node job UP within one scrape interval. If it shows context deadline exceeded, that is the firewall from step 3 doing its job too well - re-check the allow rule.

5. The five metrics that matter (out of a thousand)

The /metrics page is a firehose. These are the series worth queries and alerts on day one:

• node_filesystem_avail_bytes - free disk. The good alert is not “90% full” but “full within 4 hours at the current rate”: predict_linear(node_filesystem_avail_bytes{fstype!~"tmpfs"}[1h], 4*3600) < 0.
• node_memory_MemAvailable_bytes - the honest memory metric. Ignore MemFree, which Linux keeps low on purpose; MemAvailable accounts for reclaimable cache.
• node_cpu_seconds_total - CPU usage by mode. Sustained saturation: 1 - avg by (instance) (rate(node_cpu_seconds_total{mode="idle"}[5m])). On VMs, also watch mode="steal" - steal above a few percent means a noisy neighbour or an oversold host, and no amount of local tuning fixes it.
• node_load15 vs CPU count - node_load15 / count by (instance) (node_cpu_seconds_total{mode="idle"}) above ~1.5 means work is queueing.
• up - the scrape itself. up{job="node"} == 0 is the alert that catches a dead exporter, a dead host, or a broken network path. Without it, every other alert fails silent instead of loud.

A ready-made set of fifteen rules built on exactly these - thresholds, for: durations, annotations - is in Prometheus alert rules for Linux servers, and Alertmanager turns them into notifications.

Bonus: the textfile collector

The most underused node_exporter feature. Any script can drop a .prom file into a directory and its numbers become Prometheus metrics - backup age, cert days remaining, queue depth, anything:

# in the systemd unit: --collector.textfile.directory=/var/lib/node_exporter
echo "backup_last_success_timestamp $(date +%s)" \
  | sudo tee /var/lib/node_exporter/backup.prom

Alert on time() - backup_last_success_timestamp > 86400 * 2 and the silent-backup-failure class of incident disappears.

The half node_exporter cannot see

node_exporter reports what the host believes about itself, scraped from inside the network. It has no opinion on whether users can actually reach the site, whether the TLS certificate is about to expire, whether the domain renews - or whether the Prometheus server scraping it is still alive, since a monitoring stack cannot alert on its own death. The standard fix is cheap: pair the internal stack with external checks. AlertKick’s free monitors probe HTTP, TCP, DNS, SSL, and domain expiry from the outside and page through real escalation chains (Slack, Telegram, phone, on-call rotations), and a one-line heartbeat from the Prometheus host closes the who-watches-the-watcher loop. Set both up free - the two halves make one whole picture.
